Reverse Engineering Microchip IC PIC12F683 memory and read mcu pic12f683 software in the format of heximal from flash memory, fuse bit of microcontroller will be broken;

High-Performance RISC CPU:

· Only 35 instructions to learn:

– All single-cycle instructions except branches

· Operating speed:

– DC – 20 MHz oscillator/clock input

– DC – 200 ns instruction cycle

· Interrupt capability

· 8-level deep hardware stack

– Direct, Indirect and Relative Addressing modes

Special Microcontroller Features:

· Precision Internal Oscillator:

– Factory calibrated to ±1%, typical if unlock avr mcu at90can64 microcontroller flash memory

– Software selectable frequency range of 8 MHz to 125 kHz

– Software tunable

– Two-Speed Start-up mode

– Crystal fail detect for critical applications

– Clock mode switching during operation for power savings

· Power-Saving Sleep mode

· Wide operating voltage range (2.0V-5.5V)

· Industrial and Extended temperature range

· Power-on Reset (POR)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Brown-out Reset (BOR) with software control option

· Enhanced Low-Current Watchdog Timer (WDT) with on-chip oscillator (software selectable nominal 268 seconds with full prescaler) with software enable

· Multiplexed Master Clear with pull-up/input pin

· Programmable code protection

· High Endurance Flash/EEPROM cell;

– 100,000 write Flash endurance

– 1,000,000 write EEPROM endurance

– Flash/Data EEPROM Retention: > 40 years

Low-Power Features:

· Standby Current:

– 50 nA @ 2.0V, typical

· Operating Current:

– 11 ìA @ 32 kHz, 2.0V, typical

– 220 ìA @ 4 MHz, 2.0V, typical

· Watchdog Timer Current:

– 1 ìA @ 2.0V, typical

· 6 I/O pins with individual direction control:

– High current source/sink for direct LED drive

– Interrupt-on-pin change

– Individually programmable weak pull-ups

– Ultra Low-Power Wake-up on GP0 for the purpose of unlock Microchip mcu pic24fj256gb206 memory

· Analog Comparator module with:

– One analog comparator

– Programmable on-chip voltage reference (CVREF) module (% of VDD)

– Comparator inputs and output externally accessible

· A/D Converter:

– 10-bit resolution and 4 channels

· Timer0: 8-bit timer/counter with 8-bit programmable prescaler

· Enhanced Timer1:

– 16-bit timer/counter with prescaler

– External Timer1 Gate (count enable)

– Option to use OSC1 and OSC2 in LP mode as Timer1 oscillator if INTOSC mode selected

· Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

· Capture, Compare, PWM module:

– 16-bit Capture, max resolution 12.5 ns

– Compare, max resolution 200 ns

– 10-bit PWM, max frequency 20 kHz

· In-Circuit Serial Programming™ (ICSP™) via two pins by the end
