Restore DSP IC Controller Texas Instruments TMS320F241PG

restore-dsp-ic-controller-texas-instruments-tms320f241pg

We can clone IC Controller Texas Instruments TMS320F241PG, please view the chip features below for your reference:



High-Performance Static CMOS Technology

D Includes the T320C2xx Core CPU

– Object-Compatible With the TMS320C2xx

– Source-Code-Compatible With

TMS320C25



D Single 10-Bit Analog-to-Digital Converter

(ADC) Module With 8 Multiplexed Input

Channels

D 26 Individually Programmable, Multiplexed

General-Purpose I / O (GPIO) Pins



Upwardly Compatible With TMS320C5x

– 50-ns Instruction Cycle Time

Pin Compatible to Emulation Device

TMS320F241 (64-Pin/68-Pin)

Code Compatible to Emulation Devices

TMS320F243 and TMS320F241

Commercial and Industrial Temperature

Available

Memory

– 544 Words x 16 Bits of On-Chip

Data/Program Dual-Access RAM

(DARAM)

– 4K Words x 16 Bits of On-chip

Program ROM

Event-Manager Module

– Eight Compare/ Pulse-Width Modulation

(PWM) Channels

– Two 16-Bit General-Purpose Timers With

Six Modes, Including Continuous Up and

Up / Down Counting

– Three 16-Bit Full Compare Units With



Phase-Locked-Loop (PLL)-Based Clock

Watchdog (WD) Timer Module

Serial Communications Interface (SCI)

Five External Interrupts (Power Drive

Protection, Reset, NMI, and Two Maskable

Interrupts)

Three Power-Down Modes for Low-Power

Operation

Scan-Based Emulation

Development Tools Available:

– Texas Instruments (TI™) ANSI C

Compiler, Assembler / Linker, and

C-Source Debugger

– Full Range of Emulation Products

– Self-Emulation (XDS510™)

– Third-Party Digital Motor Control and

Fuzzy-Logic Development Support

68-Pin PLCC FN Package

64-Pin QFP PG Package



Deadband

– Three Capture Units (Two With

Quadrature Encoder-Pulse Interface

Capability)

The TMS320C242 device is a member of the ’24x family of digital signal processor (DSP) controllers based on

the TMS320C2xx generation of 16-bit fixed-point DSPs. The TMS320F241 device is fully compatible with the

’C242 to allow emulation during prototype development. (These two devices share similar core and

peripherals.) This new family is optimized for digital motor / motion control applications. The DSP controllers

combine the enhanced TMS320 architectural design of the ’C2xx core CPU for low-cost, high-performance

processing capabilities and several advanced peripherals optimized for motor/motion control applications.

These peripherals include the event manager module, which provides general-purpose timers and PWM

registers to generate PWM outputs, and a single,10-bit analog-to-digital converter (ADC), which can perform

conversion within 1 µs.
