Replicate Renesas MCU R5F11EB8AFP#50 Flash Content needs to break renesas microcontroller tamper resistance system by focus ion beam and then extract secured code from processor flash memory;

The measurement condition is Topr = -20 to 85°C (N version) / -40 to 85°C (D version), unless otherwise specified.

This condition (external power VCC rise gradient) does not apply if VCC ³ 1.0 V when clone renesas r5f21192 flash memory content.

To use the power-on reset function, enable voltage monitor 0 reset by setting the LVD0ON bit in the OFS register to 0, the VW0C0 and VW0C6 bits in the VW0C register to 1 respectively, and the VCA25 bit in the VCA2 register to 1.

tw(por1) indicates the duration the external power VCC must be held below the effective voltage (Vpor1) to enable a power on reset. When turning on the power for the first time, maintain tw(por1) for 30 s or more if -20°C £ Topr £ 85°C, maintain tw(por1) for 3,000 s or more if -40°C £ Topr < -20°C

1. The measurement condition is VCC = 2.2 to 5.5 V and Topr = -20 to 85°C (N version) / -40 to 85°C (D version).
2. 2.      Necessary time until the voltage detection circuit operates when setting to 1 again after setting the VCA25 bit in the VCA2 register to 0.
