Microchip PIC16F1613T MCU Flash Firmware Unlocking means reading out flash memory content from microcontroller pic16f1613t. protective system of microprocessor pic16f1613t will be reverse engineered;

Once Synchronous mode is selected, reception is enabled by setting either the Single Receive Enable bit, SREN (RCSTA<5>), or the Continuous Receive Enable bit, CREN (RCSTA<4>). Data is sampled on the RB4/AN6/RX/DT/KBI0 pin on the falling edge of the clock.

If enable bit, SREN, is set, only a single word is received. If enable bit, CREN, is set, the reception is continuous until CREN is cleared to attack microcomputer pic16f1827 tamper resistance system. If both bits are set, then CREN takes precedence.

To set up a Synchronous Master Reception:

1. Initialize the SPBRGH:SPBRG registers for the appropriate baud rate. Set or clear the BRGH and BRG16 bits, as required, to achieve the desired baud rate.

Enable the synchronous master serial port by setting bits SYNC, SPEN and CSRC.

Ensure bits CREN and SREN are clear.

If interrupts are desired, set enable bit RCIE.

If 9-bit reception is desired, set bit RX9.

If a single reception is required, set bit SREN. For continuous reception, set bit CREN.

Interrupt flag bit, RCIF, will be set when reception is complete and an interrupt will be generated if the enable bit by cracking microcontroller pic18f8722 flash memory, RCIE, was set.

Read the RCSTA register to get the ninth bit (if enabled) and determine if any error occurred during reception.

Read the 8-bit received data by reading the RCREG register.

If any error occurred, clear the error by clearing bit CREN.

If using interrupts, ensure that the GIE and PEIE bits in the INTCON register (INTCON<7:6>) are set.
