Unlock IC PIC18F2220 Software

We can Unlock IC PIC18F2220 Software, please view the IC PIC18F2220 features for your reference:

Low-Power Features:

· Power Managed modes:

– Run: CPU on, peripherals on

– Idle: CPU off, peripherals on

– Sleep: CPU off, peripherals off

· Power Consumption modes:

– PRI_RUN: 150 µA, 1 MHz, 2V

– PRI_IDLE: 37 µA, 1 MHz, 2V when Unlock IC

– SEC_RUN: 14 µA, 32 kHz, 2V

– SEC_IDLE: 5.8 µA, 32 kHz, 2V

– RC_RUN: 110 µA, 1 MHz, 2V

– RC_IDLE: 52 µA, 1 MHz, 2V

– Sleep: 0.1 µA, 1 MHz, 2V

· Timer1 Oscillator: 1.1 µA, 32 kHz, 2V if Unlock IC

· Watchdog Timer: 2.1 µA

· Two-Speed Oscillator Start-up

Oscillators:

· Four Crystal modes:

– LP, XT, HS: up to 25 MHz

– HSPLL: 4-10 MHz (16-40 MHz internal)

· Two External RC modes, up to 4 MHz

· Two External Clock modes, up to 40 MHz before Unlock IC

· Internal oscillator block:

– 8 user selectable frequencies: 31 kHz, 125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz, 4 MHz, 8 MHz

– 125 kHz-8 MHz calibrated to 1%

– Two modes select one or two I/O pins

– OSCTUNE – Allows user to shift frequency

· Secondary oscillator using Timer1 @ 32 kHz after Unlock IC

· Fail-Safe Clock Monitor

– Allows for safe shutdown if peripheral clock stops

Peripheral Highlights:

· High current sink/source 25 mA/25 mA

· Three external interrupts

· Up to 2 Capture/Compare/PWM (CCP) modules:

– Capture is 16-bit, max. resolution is 6.25 ns (TCY/16)

– Compare is 16-bit, max. resolution is 100 ns (TCY) when Unlock IC

– PWM output: PWM resolution is 1 to 10-bit

· Enhanced Capture/Compare/PWM (ECCP) module:

– One, two or four PWM outputs

– Selectable polarity

– Programmable dead-time

– Auto-Shutdown and Auto-Restart if Unlock IC

· Compatible 10-bit, up to 13-channel Analog-to-Digital Converter module (A/D) with programmable acquisition time

· Dual analog comparators

· Addressable USART module:

– RS-232 operation using internal oscillator block (no external crystal required)

Special Microcontroller Features:

· 100,000 erase/write cycle Enhanced Flash program memory typical before Unlock IC

· 1,000,000 erase/write cycle Data EEPROM memory typical

· Flash/Data EEPROM Retention: > 40 years

· Self-programmable under software control

· Priority levels for interrupts

· 8 x 8 Single-Cycle Hardware Multiplier

· Extended Watchdog Timer (WDT):

– Programmable period from 41 ms to 131s

– 2% stability over VDD and Temperature after Unlock IC

· Single-supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins

· In-Circuit Debug (ICD) via two pins

· Wide operating voltage range: 2.0V to 5.5V
