We can Unlock ATMEL IC ATtiny861 8-bit Microcontroller, please view the mcu chip features for your reference:

Features

· High Performance, Low Power AVR® 8-Bit Microcontroller

· Advanced RISC Architecture

– 123 Powerful Instructions – Most Single Clock Cycle Execution

– 32 x 8 General Purpose Working Registers

Fully Static Operation



Non-volatile Program and Data Memories

– 2/4/8K Byte of In-System Programmable Program Memory Flash



(ATtiny261/461/861)

Endurance: 10,000 Write/Erase Cycles

– 128/256/512 Bytes In-System Programmable EEPROM (ATtiny261/461/861)

Endurance: 100,000 Write/Erase Cycles

– 128/256/512 Bytes Internal SRAM (ATtiny261/461/861)

– Programming Lock for Self-Programming Flash Program and EEPROM Data



8-bit Microcontroller with 2/4/8K

Security

Peripheral Features

– 8/16-bit Timer/Counter with Prescaler and Two PWM Channels

– 8/10-bit High Speed Timer/Counter with Separate Prescaler

3 High Frequency PWM Outputs with Separate Output Compare Registers

Programmable Dead Time Generator

– Universal Serial Interface with Start Condition Detector

– 10-bit ADC

11 Single Ended Channels

16 Differential ADC Channel Pairs

15 Differential ADC Channel Pairs with Programmable Gain (1x, 8x, 20x, 32x)

Programmable Watchdog Timer with Separate On-chip Oscillator

– On-chip Analog Comparator

Unlock ATMEL IC ATtiny861 8-bit Microcontroller

Unlock ATMEL IC ATtiny861 8-bit Microcontroller

Special Microcontroller Features

– debugWIRE On-chip Debug System

– In-System Programmable via SPI Port

External and Internal Interrupt Sources

– Low Power Idle, ADC Noise Reduction, and Power-down Modes

– Enhanced Power-on Reset Circuit

– Programmable Brown-out Detection Circuit

– Internal Calibrated Oscillator

I/O and Packages

– 16 Programmable I/O Lines

20-pin PDIP, 20-pin SOIC and 32-pad MLF

Operating Voltage:

– 1.8 – 5.5V for ATtiny261V/461V/861V

– 2.7 – 5.5V for ATtiny261/461/861

Speed Grade:

– ATtiny261V/461V/861V: 0 – 4 MHz @ 1.8 – 5.5V, 0 – 10 MHz @ 2.7 – 5.5V

– ATtiny261/461/861: 0 – 10 MHz @ 2.7 – 5.5V, 0 – 20 MHz @ 4.5 – 5.5V

Industrial Temperature Range

Low Power Consumption



Bytes In-System Programmable Flash

ATtiny261/V

ATtiny461/V

ATtiny861/V



– Active Mode: 1 MHz, 1.8V: 380ìA

– Power-down Mode: 0.1ìA at 1.8V
