Read Microcontroller PIC16F690 Heximal

We can Read Microcontroller PIC16F690 Heximal, please view the Microcontroller PIC16F684 features for your reference:



High-Performance RISC CPU:

· Only 35 instructions to learn:

– All single-cycle instructions except branches

· Operating speed:

– DC – 20 MHz oscillator/clock input

– DC – 200 ns instruction cycle when Read Microcontroller

· Interrupt capability

· 8-level deep hardware stack



Low-Power Features:

· Standby Current:

– 1 nA @ 2.0V, typical

· Operating Current:

– 8.5 µA @ 32 kHz, 2.0V, typical

– 100 µA @ 1 MHz, 2.0V, typical

· Watchdog Timer Current:

– 1 µA @ 2.0V, typical

· Direct, Indirect and Relative Addressing modes if Read Microcontroller

Peripheral Features:



Special Microcontroller Features:

· Precision Internal Oscillator:

– Factory calibrated to ±1%

– Software selectable frequency range of 8 MHz to 31 kHz

– Software tunable

– Two-speed Start-up mode

– Crystal fail detect for critical applications

– Clock mode switching during operation for power savings after Read Microcontroller

· Power-saving Sleep mode

· Wide operating voltage range (2.0V-5.5V)

· Industrial and Extended Temperature range

· Power-on Reset (POR)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Brown-out Detect (BOD) with software control option

· Enhanced low-current Watchdog Timer (WDT) with on-chip oscillator (software selectable nominal 268 seconds with full prescaler) with software enable

· Multiplexed Master Clear with pull-up/input pin if Read Microcontroller

· Programmable code protection

· High Endurance Flash/EEPROM cell:

– 100,000 write Flash endurance

– 1,000,000 write EEPROM endurance

– Flash/Data EEPROM retention: > 40 years



· 12 I/O pins with individual direction control:

– High current source/sink for direct LED drive before Read Microcontroller

– Interrupt-on-pin change

– Individually programmable weak pull-ups

– Ultra Low-power Wake-up (ULPWU)

· Analog comparator module with:

– Two analog comparators

– Programmable on-chip voltage reference (CVREF) module (% of VDD)

– Comparator inputs and outputs externally accessible

· A/D Converter:

– 10-bit resolution and 8 channels

· Timer0: 8-bit timer/counter with 8-bit programmable prescaler

· Enhanced Timer1:

– 16-bit timer/counter with prescaler after Read Microcontroller

– External Gate Input mode

– Option to use OSC1 and OSC2 in LP mode as Timer1 oscillator if INTOSC mode selected

· Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

· Enhanced Capture, Compare, PWM module:

– 16-bit Capture, max resolution 12.5 ns

– Compare, max resolution 200 ns

– 10-bit PWM with 1, 2 or 4 output channels, programmable “dead time”, max frequency 20 kHz

· In-Circuit Serial ProgrammingTM (ICSPTM) via two pins only after Read Microcontroller.
