Pull Microcontroller IC Microchip PIC24HJ64GP506 16-Bit MCU

We can pull the information from Microchip PIC24HJ64GP506 16-Bit MCU microcontroller unlock, please find the IC chip features below for your reference, wait for your prompt response:

Operating Range:

· Up to 40 MIPS operation (at 3.0-3.6V):

– Industrial temperature range

(-40°C to +85°C)

– Extended temperature range

(-40°C to +125°C)

High-Performance CPU:

On-Chip Flash and SRAM:

· Flash program memory, up to 256 Kbytes

· Data SRAM, up to 16 Kbytes (includes 2 Kbytes

of DMA RAM)

System Management:

· Flexible clock options:

Modified Harvard architecture

C compiler optimized instruction set

16-bit wide data path

24-bit wide instructions

Linear program memory addressing up to 4M

instruction words

Linear data memory addressing up to 64 Kbytes

71 base instructions: mostly 1 word/1 cycle

Sixteen 16-bit General Purpose Registers

Flexible and powerful Indirect Addressing modes

Software stack

16 x 16 multiply operations

32/16 and 16/16 divide operations

External, crystal, resonator, internal RC

– Fully integrated PLL

– Extremely low jitter PLL

· Power-up Timer

· Oscillator Start-up Timer/Stabilizer

· Watchdog Timer with its own RC oscillator

· Fail-Safe Clock Monitor

· Reset by multiple sources

Power Management:

· On-chip 2.5V voltage regulator

· Switch between clock sources in real time

· Idle, Sleep and Doze modes with fast wake-up

· Up to ±16-bit data shifts

Direct Memory Access (DMA):

· 8-channel hardware DMA

· 2 Kbytes dual ported DMA buffer area

(DMA RAM) to store data transferred via DMA:

– Allows data transfer between RAM and a

peripheral while CPU is executing code

(no cycle stealing)

· Most peripherals support DMA

Interrupt Controller:

Timers/Capture/Compare/PWM:

· Timer/Counters, up to nine 16-bit timers:

– Can pair up to make four 32-bit timers

– One timer runs as Real-Time Clock with

external 32.768 kHz oscillator

– Programmable prescaler

· Input Capture (up to eight channels):

– Capture on up, down or both edges

– 16-bit capture input functions

– 4-deep FIFO on each capture

5-cycle latency

Up to 61 available interrupt sources

Up to five external interrupts

Seven programmable priority levels

FIve processor exceptions

· Output Compare (up to eight channels):

– Single or Dual 16-Bit Compare mode

– 16-bit Glitchless PWM mode

Digital I/O:

Up to 85 programmable digital I/O pins

Wake-up/Interrupt-on-Change on up to 24 pins

Output pins can drive from 3.0V to 3.6V

All digital input pins are 5V tolerant

4 mA sink on all I/O pins
