Protected Microcontroller PIC18F2480 Heximal Cracking

Protected Microcontroller PIC18F2480 Heximal Cracking will remove the protection against the Microcontroller embedded firmware and read out the program directly from the memory:

The Internal Oscillator Frequency Select bits (IRCF2:IRCF0) select the frequency output of the internal oscillator block to drive the device clock.

Protected Microcontroller PIC18F2480 Heximal Cracking

Protected Microcontroller PIC18F2480 Heximal Cracking

The choices are the INTRC source, the INTOSC source (8 MHz) or one of the frequencies derived from the INTOSC postscaler (31.25 kHz to 4 MHz). If the internal oscillator block is supplying the device clock,changing the states of these bits will have an immediate change on the internal oscillator’s output.

On device Resets, the default output frequency of the internal oscillator block is set at 1 MHz when crack the heximal from protected microcontroller.
When a nominal output frequency of 31 kHz is selected (IRCF2:IRCF0 = 000), users may choose which internal oscillator acts as the source. This is done with the INTSRC bit in the OSCTUNE register (OSCTUNE<7>). Setting this bit selects INTOSC as a 31.25 kHz clock source by enabling the divide-by-256 output of the INTOSC postscaler. Clearing INTSRC selects INTRC (nominally 31 kHz) as the clock source.
This option allows users to select the tunable and more precise INTOSC as a clock source, while maintaining power savings with a very low clock speed. Regardless of the setting of INTSRC, INTRC always remains the clock source for features such as the Watchdog Timer and the Fail-Safe Clock Monitor.

The OSTS, IOFS and T1RUN bits indicate which clock source is currently providing the device clock. The OSTS bit indicates that the Oscillator Start-up Timer has timed out and the primary clock is providing the device clock in primary clock modes.

The IOFS bit indicates when the internal oscillator block has stabilized and is providing the device clock in RC Clock modes.
The T1RUN bit (T1CON<6>) indicates when the Timer1 oscillator is providing the device clock in secondary clock modes. In power managed modes, only one of these three bits will be set at any time. If none of these bits are set, the INTRC is providing the clock or the internal oscillator block has just started and is not yet stable.
