Hack Microcontroller Chip Texas MSP430F448

We can hack Microcontroller Chip Texas MSP430F448, please view below IC features for your reference:

Low Supply-Voltage Range, 1.8 V to 3.6 V

Ultralow-Power Consumption:

– Active Mode: 280 µA at 1 MHz, 2.2 V

– Standby Mode: 1.1 µA

– Off Mode (RAM Retention): 0.1 µA

Five Power Saving Modes

Wake-Up From Standby Mode in 6 µs 16-Bit RISC Architecture,

125-ns Instruction Cycle Time

12-Bit A/D Converter With Internal

Reference, Sample-and-Hold and Autoscan

Feature

16-Bit Timer With Three† or Seven‡

Capture/Compare-With-Shadow Registers,

Timer_B



Serial Onboard Programming,

No External Programming Voltage Needed

Programmable Code Protection by Security Fuse

Integrated LCD Driver for Up to 160 Segments

Family Members Include:

– MSP430F435:

16KB+256B Flash Memory,

512B RAM

– MSP430F436:

24KB+256B Flash Memory,

1KB RAM

– MSP430F437:

32KB+256B Flash Memory,

1KB RAM

16-Bit Timer With Three Capture/Compare

Registers, Timer_A

On-Chip Comparator

Serial Communication Interface (USART),

Select Asynchronous UART or

Synchronous SPI by Software;

Two USARTs (USART0, USART1) In

MSP430x44x Devices

One USART (USART0) In MSP430x43x

Devices

Brownout Detector

Supply Voltage Supervisor/Monitor With

Programmable Level Detection



– MSP430F447:

32KB+256B Flash Memory,

1KB RAM

– MSP430F448:

48KB+256B Flash Memory,

2KB RAM

– MSP430F449:

60KB+256B Flash Memory,

2KB RAM

For Complete Module Descriptions, See

The MSP430x4xx Family User’s Guide,

Literature Number SLAU056

† ’F435, ’F436, and ’F437 devices



‡ ’F447, ’F448, and ’F449 devices

description

The Texas Instruments MSP430 series is an ultralow-power microcontroller family consisting of several devices featuring different sets of modules targeted to various applications. The microcontroller is designed to be battery operated for use in extended-time applications. The MSP430 achieves maximum code efficiency with its 16-bit RISC architecture, 16-bit CPU-integrated registers, and a constant generator. The digitally-controlled oscillator provides wake-up from low-power mode to active mode in less than 6 µs. The MSP430x43x and the MSP430x44x series are microcontroller configurations with two built-in 16-bit timers, a fast 12-bit A/D converter, one or two universal serial synchronous/asynchronous communication interfaces (USART), 48 I/O pins, and a liquid crystal driver (LCD) with up to 160 segments when unlock microcontroller.

Typical applications include sensor systems that capture analog signals, convert them to digital values, and process and transmit the data to a host system, or process this data and displays it on a LCD panel. The timers make the configurations ideal for industrial control applications such as ripple counters, digital motor control, EE-meters, hand-held meters, etc. The hardware multiplier enhances the performance and offers a broad code and hardware-compatible family solution.
