Low-Power Features:

· Power Managed modes:

– Primary RUN: RC oscillator, 76 µA, 1 MHz, 2V

– RC_RUN: 7 µA, 31.25 kHz, 2V

– SEC_RUN: 9 µA, 32 kHz, 2V

– SLEEP: 0.1 µA, 2V

· Timer1 Oscillator: 1.8 µA, 32 kHz, 2V

· Watchdog Timer: 2.2 µA, 2V

· Two-Speed Oscillator Start-up

Oscillators:

· Three Crystal modes:

– LP, XT, HS: up to 20 MHz

· Two External RC modes

· One External Clock mode:

– ECIO: up to 20 MHz

· Internal oscillator block:

– 8 user selectable frequencies: 31 kHz, 125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz, 4 MHz, 8 MHz

Peripheral Features:

· Capture, Compare, PWM (CCP) module:

– Capture is 16-bit, max. resolution is 12.5 ns

– Compare is 16-bit, max. resolution is 200 ns

– PWM max. resolution is 10-bit

· 10-bit, 7-channel Analog-to-Digital Converter

· Synchronous Serial Port (SSP) with SPI™ (Master/Slave) and I2C™ (Slave)

· Addressable Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI) with 9-bit address detection if XILINX CPLD XC18V04PC44C prom hacking:

– RS-232 operation using internal oscillator (no external crystal required)

· Dual Analog Comparator module:

– Programmable on-chip voltage reference

– Programmable input multiplexing from device inputs and internal voltage reference

– Comparator outputs are externally accessible

Special Microcontroller Features:

· 100,000 erase/write cycles Enhanced FLASH program memory typical

· 1,000,000 typical erase/write cycles EEPROM data memory typical

· EEPROM Data Retention: > 40 years

· In-Circuit Serial Programming™ (ICSP™) – via two pins

· Processor read/write access to program memory

· Low-Voltage Programming

· In-Circuit Debugging via two pins

· Extended Watchdog Timer (WDT):

– Programmable period from 1 ms to 268s

· Wide operating voltage range: 2.0V to 5.5V
