we can Discover MCU Analog Devices ADUC831BSZ, please find below MCU features for your reference:

EATURES

ANALOG I/O

FUNCTIONAL BLOCK DIAGRAM

8-Channel, 247 kSPS 12-Bit ADC

DC Performance: 1 LSB INL



ADuC831

12-BIT

DAC BUF DAC

AC Performance: 71 dB SNR

DMA Controller for High Speed ADC-to-RAM Capture

2 12-Bit (Monotonic) Voltage Output DACs

Dual Output PWM/ – DACs

On-Chip Temperature Sensor Function 3 C



ADC0

ADC1

MUX

T/H 12-BIT ADC 12-BIT DAC 16-BIT

– DAC BUF DAC



On-Chip Voltage Reference

ADC5

Memory

62 kBytes On-Chip Flash/EE Program Memory

4 kBytes On-Chip Flash/EE Data Memory



ADC6

ADC7



TEMP

HARDWARE

CALIBRATON



16-BIT

– DAC

16-BIT

PWM



MUX

PWM0

PWM1



Flash/EE, 100 Yr Retention, 100 kCycles Endurance

2304 Bytes On-Chip Data RAM

8051 Based Core

8051 Compatible Instruction Set (16 MHz Max)

12 Interrupt Sources, 2 Priority Levels

Dual Data Pointer



SENSOR

16-BIT

PWM 8051-BASED MCU WITH ADDITIONAL

PERIPHERALS

62 kBYTES FLASH/EE PROGRAM MEMORY

4 kBYTES FLASH/EE DATA MEMORY

2304 BYTES USER RAM



Extended 11-Bit Stack Pointer



3



16 BIT TIMERS



POWER SUPPLY MON



On-Chip Peripherals

Time Interval Counter (TIC)

UART, I2C®, and SPI® Serial I/O

Watchdog Timer (WDT), Power Supply Monitor (PSM)



INTERNAL

BAND GAP

VREF

VREF



OSC

XTAL1

XTAL2



1



REAL TIME CLOCK

PARALLEL

PORTS



WATCHDOG TIMER

UART, I2 C, AND SPI

SERIAL I/O



Power

Specified for 3 V and 5 V Operation

Normal, Idle, and Power-Down Modes

Power-Down: 20 A @ 3 V

APPLICATIONS

Optical Networking—Laser Power Control

Base Station Systems

Precision Instrumentation, Smart Sensors

Transient Capture Systems

DAS and Communications Systems

Pin compatible upgrade to existing ADuC812 systems that require additional code or data memory. Runs from 1 MHz–16 MHz to external crystal.

The ADuC832 is also available. Functionally is the same as the ADuC831, except the ADuC832 runs from a 32 kHz external crystal with on-chip PLL.
