Decrypt Microcontroller Microchip PIC16F724 20-Pin Flash

We can decrypt Microchip PIC16F724 20-Pin Flash microcontroller, please view the IC chip features for your reference:

High-Performance RISC CPU:

· Only 35 Instructions to Learn:

– All single-cycle instructions except branches

· Operating Speed:

– DC – 16 MHz oscillator/clock input

– DC – 250 ns instruction cycle

· Up to 4K x 14 Words of Flash Program Memory

· Up to 256 bytes of Data Memory (RAM)

· Interrupt Capability

· 8-Level Deep Hardware Stack

· Direct, Indirect and Relative Addressing modes

· Processor Self-Write/Read access to Program

Memory

Special Microcontroller Features:

· Precision Internal Oscillator:

– 16 MHz or 500 kHz operation

– Factory calibrated to ±1%, typical

– Software tunable

– Software selectable ÷1, ÷2, ÷4 or ÷8 divider

· Power-Saving Sleep mode

· Industrial and Extended Temperature Range

· Power-on Reset (POR)

· Power-up Timer (PWRT)

· Brown-out Reset (BOR)

· Multiplexed Master Clear with Pull-up/Input Pin

· Programmable Code Protection

· In-Circuit Serial ProgrammingTM (ICSPTM) via Two

Pins

· 128 Bytes High-Endurance Flash:

100,000 write Flash endurance (minimum)

· Wide Operating Voltage Range:

– 1.8V to 5.5V (PIC16F720/721)

– 1.8V to 3.6V (PIC16LF720/721)

– 500 nA @ 1.8V, typical

Peripheral Features:

· Up to 17 I/O Pins and 1 Input-only Pin:

High-current source/sink for direct LED drive

– Interrupt-on-change pins

– Individually programmable weak pull-ups

· A/D Converter:

– 8-bit resolution

– 12 channels

– Selectable Voltage reference

· Timer0: 8-Bit Timer/Counter with 8-Bit

Programmable Prescaler

· Enhanced Timer1

– 16-bit timer/counter with prescaler

External Gate Input mode with toggle and

single shot modes

– Interrupt-on-gate completion

· Timer2: 8-Bit Timer/Counter with 8-Bit Period

Register, Prescaler and Postscaler

· Capture, Compare, PWM module (CCP)

– 16-bit Capture, max resolution 12.5 ns

– 16-bit Compare, max resolution 250 ns

– 10-bit PWM, max frequency 15 kHz

· Addressable Universal Synchronous

Asynchronous Receiver Transmitter (AUSART)

· Synchronous Serial Port (SSP)

– SPI (Master/Slave)

– I2CTM (Slave) with Address Mask



· 128 Bytes High-Endurance Flash:

– 100,000 write Flash endurance (minimum)

· Wide Operating Voltage Range:

1.8V to 5.5V (PIC16F720/721)

– 1.8V to 3.6V (PIC16LF720/721)
