Decrypt atmel avr mcu chip ATTINY26 8-bit Microcontroller with 2K Bytes Flash

We can decrypt atmel avr mcu chip attiny26 8-bit Microcontroller with 2K Bytes Flash, please view the IC microcontroller features for your reference:

Features

· High-performance, Low-power AVR ® 8-bit Microcontroller

· RISC Architecture

– 118 Powerful Instructions – Most Single Clock Cycle Execution

– 32 x 8 General Purpose Working Registers

– Fully Static Operation

– Up to 16 MIPS Throughput at 16 MHz

Data and Non-volatile Program Memory

– 2K Bytes of In-System Programmable Program Memory Flash



Endurance: 10,000 Write/Erase Cycles

– 128 Bytes of In-System Programmable EEPROM

Endurance: 100,000 Write/Erase Cycles

– 128 Bytes Internal SRAM

– Programming Lock for Flash Program and EEPROM Data Security

8-bit Microcontroller



Peripheral Features

– 8-bit Timer/Counter with Separate Prescaler

8-bit High-speed Timer with Separate Prescaler

2 High Frequency PWM Outputs with Separate Output Compare Registers

Non-overlapping Inverted PWM Output Pins

– Universal Serial Interface with Start Condition Detector

10-bit ADC

11 Single Ended Channels

8 Differential ADC Channels

7 Differential ADC Channel Pairs with Programmable Gain (1x, 20x)

– On-chip Analog Comparator

– External Interrupt

Pin Change Interrupt on 11 Pins

– Programmable Watchdog Timer with Separate On-chip Oscillator

Special Microcontroller Features

– Low Power Idle, Noise Reduction, and Power-down Modes

– Power-on Reset and Programmable Brown-out Detection

– External and Internal Interrupt Sources

– In-System Programmable via SPI Port

– Internal Calibrated RC Oscillator

I/O and Packages

20-lead PDIP/SOIC: 16 Programmable I/O Lines

– 32-lead MLF: 16 programmable I/O Lines

Operating Voltages

– 2.7V – 5.5V for ATtiny26L

– 4.5V – 5.5V for ATtiny26

Speed Grades

– 0 – 8 MHz for ATtiny26L

– 0 – 16 MHz for ATtiny26

Power Consumption at 1 MHz, 3V and 25°C for ATtiny26L

– Active 16 MHz, 5V and 25°C: Typ 15 mA

– Active 1 MHz, 3V and 25°C: 0.70 mA

– Idle Mode 1 MHz, 3V and 25°C: 0.18 mA


with 2K Bytes Flash

ATtiny26

ATtiny26L



Power-down Mode: < 1 µA
