Decode PIC MCU Microchip PIC16C52-04/P – ROM-Based 8-Bit CMOS Microcontroller

We can decode PIC MCU Microchip PIC16C52-04/P – ROM-Based 8-Bit CMOS Microcontroller, please view the IC MCU chip features for your reference:



High-Performance RISC CPU:

· Only 33 single word instructions to learn

· All instructions are single cycle (200 ns) except for

program branches which are two-cycle

· Operating speed: DC – 20 MHz clock input

DC – 200 ns instruction cycle

· 12-bit wide instructions

· 8-bit wide data path

· Seven or eight special function hardware registers

· Two-level deep hardware stack

· Direct, indirect and relative addressing modes for



data and instructions


SSOP


Peripheral Features:

· 8-bit real time clock/counter (TMR0) with 8-bit

programmable prescaler

· Power-On Reset (POR)

· Device Reset Timer (DRT)

· Watchdog Timer (WDT) with its own on-chip

RC oscillator for reliable operation

· Programmable code-protection

· Power saving SLEEP mode

· Selectable oscillator options:

– RC:    Low-cost RC oscillator

– XT:    Standard crystal/resonator

– HS:    High-speed crystal/resonator

LP:    Power saving, low-frequency crystal

CMOS Technology:

· Low-power, high-speed CMOS ROM technology

· Fully static design

· Wide-operating voltage and temperature range:

ROM Commercial/Industrial 3.0V to 5.5V

· Low-power consumption

– < 2 mA typical @ 5V, 4 MHz

– 15 µA typical @ 3V, 32 kHz

The PIC16C5X from Microchip Technology is a family of low-cost, high performance, 8-bit, fully static,

EPROM/ ROM-based CMOS microcontrollers. It employs a RISC architecture with only 33 single word/single cycle instructions. All instructions are single cycle (200 ns) except for program branches which take two cycles. The PIC16C5X delivers performance an order of magnitude higher than its competitors in the same price category. The 12-bit wide instructions are highly symmetrical resulting in 2:1 code compression over other 8-bit microcontrollers in its class. The easy to use and easy to remember instruction set reduces development time significantly.

The PIC16C5X products are equipped with special features that reduce system cost and power requirements.

The Power-On Reset (POR) and Device Reset Timer (DRT) eliminate the need for external reset circuitry.

There are four oscillator configurations to choose from, including the power-saving LP (Low Power) oscillator and cost saving RC oscillator. Power saving SLEEP mode, Watchdog Timer and code protection features improve system cost, power and reliability.

The UV erasable CERDIP packaged versions are ideal for code development, while the cost-effective One

Time Programmable (OTP) versions are suitable for production in any volume. The customer can take full advantage of Microchip’s price leadership in OTP microcontrollers while benefiting from the OTP’s flexibility.


The PIC16C5X series fits perfectly in applications ranging from high-speed automotive and appliance motor control to low-power remote transmitters/receivers, pointing devices and telecom processors. The EPROM technology makes customizing application programs (transmitter codes, motor speeds, receiver frequencies, etc.) extremely fast and convenient. The small

footprint packages, for through hole or surface mounting, make this microcontroller series perfect for applications with space limitations. Low-cost, low-power, high performance, ease of use and I/O flexibility make the PIC16C5X series very versatile even in areas where no microcontroller use has been considered before (e.g., timer functions, replacement of “glue” logic in larger systems, coprocessor applications).

full-featured macro assembler, a software simulator, an in-circuit emulator, a ‘C’ compiler, fuzzy logic support

tools, a low-cost development programmer, and a full featured programmer. All the tools are supported on

IBM® PC and compatible machines.
