Decode Microcontroller MCU Texas Instruments MSP430F15X starts from understand the basic microcontroller features and please view below various aspects:

Low Supply-Voltage Range: 1.8 V to 3.6 V

D Ultralow Power Consumption

− Active Mode: 330 ìA at 1 MHz, 2.2 V

− Standby Mode: 1.1 ìA

− Off Mode (RAM Retention): 0.2 ìA

D Five Power-Saving Modes

D Wake-Up From Standby Mode in

Less Than 6 ìs

D 16-Bit RISC Architecture,

125-ns Instruction Cycle Time

D Three-Channel Internal DMA

D 12-Bit Analog-to-Digital (A/D) Converter

With Internal Reference, Sample-and-Hold, and Autoscan Feature D Dual 12-Bit Digital-to-Analog (D/A) Converters With Synchronization D 16-Bit Timer_A With Three

Capture/Compare Registers

D 16-Bit Timer_B With Three or Seven Capture/Compare-With-Shadow Registers

D Serial Onboard Programming,

No External Programming Voltage Needed, Programmable Code Protection by Security Fuse

D Family Members Include

− MSP430F155

16KB+256B Flash Memory

512B RAM

− MSP430F156

24KB+256B Flash Memory

1KB RAM

− MSP430F157

32KB+256B Flash Memory,

1KB RAM

− MSP430F167

32KB+256B Flash Memory,

1KB RAM

− MSP430F168

48KB+256B Flash Memory,

2KB RAM

− MSP430F169

60KB+256B Flash Memory,

On-Chip Comparator

Serial Communication Interface (USART0), Functions as Asynchronous UART or Synchronous SPI or I2CTM Interface Serial Communication Interface (USART1), Functions as Asynchronous UART or Synchronous SPI Interface Supply Voltage Supervisor/Monitor With Programmable Level Detection

2KB RAM

− MSP430F1610

32KB+256B Flash Memory

5KB RAM

− MSP430F1611

48KB+256B Flash Memory

10KB RAM

− MSP430F1612

55KB+256B Flash Memory

5KB RAM

Brownout Detector

Bootstrap Loader

I2C is a registered trademark of Philips Incorporated. Available in 64-Pin QFP Package (PM) and 64-Pin QFN Package (RTD) For Complete Module Descriptions, See the MSP430x1xx Family User’s Guide,

Literature Number SLAU049 description

The Texas Instruments MSP430 family of ultralow power microcontrollers consist of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low power modes is optimized to achieve extended battery life in portable measurement applications.

The device features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 6 ìs.

This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage. ESD damage can range from subtle performance degradation to complete device failure.

Precision integrated circuits may be more susceptible to damage because very small parametric changes could cause the device not to meet its published specifications. These devices have limited built-in ESD protection. Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
