Crack IC PIC18F13K22 Binary

We can Crack IC PIC18F13K22 Binary, please view the IC PIC18F13K22 features for your reference:

High-Performance RISC CPU:

· C Compiler Optimized Architecture:

– Optional extended instruction set designed to optimize re-entrant code

· 256 bytes Data EEPROM

· Up to 16 Kbytes Linear Program Memory Addressing when Crack IC

· Up to 512 bytes Linear Data Memory Addressing

· Up to 16 MIPS Operation

· 16-bit Wide Instructions, 8-bit Wide Data Path

· Priority Levels for Interrupts

· 31-Level, Software Accessible Hardware Stack before Crack IC

· 8 x 8 Single-Cycle Hardware Multiplier

Flexible Oscillator Structure:

· Precision 16 MHz Internal Oscillator Block:

– Factory calibrated to ± 1%

– Software selectable frequencies range of 31 kHz to 16 MHz

– 64 MHz performance available using PLL – no external components required if Crack IC

· Four Crystal modes up to 64 MHz

· Two External Clock modes up to 64 MHz

· 4X Phase Lock Loop (PLL)

· Secondary Oscillator using Timer1 @ 32 kHz

· Fail-Safe Clock Monitor after Crack IC

– Allows for safe shutdown if peripheral clock stops

· Two-Speed Oscillator Start-up

Full 5.5V Operation – PIC18F1XK22

1.8V-3.6V Operation – PIC18LF1XK22

Self-reprogrammable under Software Control

Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

Programmable Brown-out Reset (BOR) before Crack IC

Extended Watchdog Timer (WDT):

– Programmable period from 4ms to 131s

Programmable Code Protection

In-Circuit Serial Programming™ (ICSP™) via two pins

In-Circuit Debug via Two Pins

Extreme Low-Power Management after Crack IC

PIC18LF1XK22 with nanoWatt XLP:

· Sleep mode: 34 nA

· Watchdog Timer: 460 nA

· Timer1 Oscillator: 650 nA @ 32 kHz

Analog Features:

· Analog-to-Digital Converter (ADC) module

– 10-bit resolution, 12 channels if Crack IC

– Auto acquisition capability

– Conversion available during Sleep

· Analog Comparator module:

– Two rail-to-rail analog comparators

– Independent input multiplexing when Crack IC

– Inputs and outputs externally accessible

· Voltage Reference module:

– Programmable (% of VDD), 16 steps

– Two 16-level voltage ranges using VREF pins

– Programmable Fixed Voltage Reference (FVR), 3 levels

Peripheral Highlights:

· 17 I/O Pins and 1 Input-only Pin:

– High current sink/source 25 mA/25 mA when Crack IC

– Programmable weak pull-ups

– Programmable interrupt-on- change

– Three external interrupt pins

· Four Timer modules:

– 3 16-bit timers/counters with prescaler

– 1 8-bit timer/counter with 8-bit period register, prescaler and postscaler

– Dedicated, low-power Timer1 oscillator

· Enhanced Capture/Compare/PWM (ECCP) module:

– One, two or four PWM outputs

– Selectable polarity

– Programmable dead time

– Auto-shutdown and Auto-restart

– PWM output steering control

· Master Synchronous Serial Port (MSSP) module

– 3-wire SPI (supports all 4 SPI modes)

– I2C™ Master and Slave modes (Slave mode address masking)

· Enhanced Universal Synchronous Asynchronous

Receiver Transmitter module (EUSART)

– Supports RS-232, RS-485 and LIN 2.0

– Auto-Baud Detect

– Auto Wake-up on Break

· SR Latch (555 Timer) module with:

– Configurable inputs and outputs

– Supports mTouch™ capacitive sensing applications
