Crack Chip PIC16F54 Eeprom

Crack Chip PIC16F54 Eeprom and its flash memory has to disable the tamper resistance system and reset the status of Microcontroller from locked to unlocked, then copy microcontroller program into other blank MCU;

Crack Chip PIC16F54 Eeprom and its flash memory has to disable the tamper resistance system and reset the status of Microcontroller from locked to unlocked,

Crack Chip PIC16F54 Eeprom and its flash memory has to disable the tamper resistance system and reset the status of Microcontroller from locked to unlocked,

High-Performance RISC CPU:

· Only 33 single-word instructions to learn

· All instructions are single cycle except for program branches which are two-cycle

· Two-level deep hardware stack

· Direct, Indirect and Relative Addressing modes for data and instructions

· Operating speed:

– DC – 20 MHz clock speed

– DC – 200 ns instruction cycle time

· On-chip Flash program memory:

– 512 x 12 on PIC16F54

– 2048 x 12 on PIC16F57

– 2048 x 12 on PIC16F59

· General Purpose Registers (SRAM) when read avr mcu atmega88:

– 25 x 8 on PIC16F54

– 72 x 8 on PIC16F57

– 134 x 8 on PIC16F59



Special Microcontroller Features:

· Power-on Reset (POR)

· Device Reset Timer (DRT)

· Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation

· Programmable Code Protection

· Power-Saving Sleep mode

· In-Circuit Serial Programming™ (ICSP™)

· Selectable oscillator options:

– RC: Low-cost RC oscillator

– XT: Standard crystal/resonator

– HS: High-speed crystal/resonator

– LP: Power-saving, low-frequency crystal

· Packages:

– 18-pin PDIP and SOIC for PIC16F54 before pulling stmicroelectronics mcu firmware

– 20-pin SSOP for PIC16F54

– 28-pin PDIP, SOIC and SSOP for PIC16F57

– 40-pin PDIP for PIC16F59

– 44-pin TQFP for PIC16F59



Low-Power Features:

· Operating Current:

– 170 ìA @ 2V, 4 MHz, typical

– 15 ìA @ 2V, 32 kHz, typical

· Standby Current:

– 500 nA @ 2V, typical

Peripheral Features:

· 12/20/32 I/O pins:

– Individual direction control

– High current source/sink

· 8-bit real-time clock/counter (TMR0) with 8-bit programmable prescaler

CMOS Technology:

· Wide operating voltage range:

– Industrial: 2.0V to 5.5V

– Extended: 2.0V to 5.5V

· Wide temperature range:

– Industrial: -40°C to 85°C

– Extended: -40°C to 125°C

· High-endurance Flash:

– 100K write/erase cycles in order to decrypt freescale microprocessor ic

– > 40-year retention

Circuit Engineering Company Limited continues to be recognized as the Southern China Leader in Services for IC Read, MCU Crack, Chip Extract, Microcontroller Unlock service. With the advancement of today’s modern circuit board technology, it is more important than ever to have specialists available to help you at a moment’s notice. Our engineering and commercial teams collectively have a vast amount of electronic experience covering field include Consumer Electronics, Industrial Automation Electronics, Wireless Communication Electronics., etc. For more information please contact us through email.
