Clone MCU TI TMS320F28044

We can clone MCU TI TMS320F28044, please view below MCU TMS320F28044 features for your reference:

F28044 Digital Signal Processor

Features

Clone MCU TI TMS320F28044

Clone MCU TI TMS320F28044

· High-Performance 100-MHz (10-ns Cycle Time) Processor

· TMS320C28x™ 32-Bit CPU

– Single-cycle 16 × 16 and 32 × 32

Multiply-accumulate (MAC) Operations

– Dual 16 × 16 MAC

– Fast Interrupt Response

– Unified Memory Programming Model

· On-Chip Memory

– 64K × 16 Flash

– 10K × 16 SARAM

– 1K × 16 OTP

– 4K × 16 Boot ROM

– Code Security Module Protects Against IC Breaking and Unauthorized Memory Access

· Clocking

– Dynamic PLL Ratio Changes Supported

– On-Chip Oscillator

– Clock-Fail-Detect Mode

· Interrupts

– Support for up to Three External Core Interrupts

– Peripheral Interrupt Expansion (PIE) Block

That Supports All Peripheral Interrupts

· High-speed, 12-Bit ADC

– 80 ns (12.5 MSPS) Conversion Rate

– 16 Channels

– Two Sample-and-Hold

– Single/Simultaneous Conversions

– Internal or External Reference

· High-Resolution PWM

– 16 Outputs with 150 ps Resolution

– 14.8 Bits at 200-kHz Switching

– 13.4 Bits at 500-kHz Switching

– 12.4 Bits at 1-MHz Switching



· Communications Port Peripherals

– Serial Peripheral Interface (SPI) Module

– Serial Communications Interface (SCI)

– Inter-Integrated Circuit (I2C) Bus

· Timers

– Three 32-bit CPU Timers

– Up to 16 16-bit Timers

– Watchdog Timer Module

· Up to 35 General-Purpose Input/Output (GPIO) Pins With Input Filtering

· On-chip JTAG Emulation With Real-time Debug via Hardware

· JTAG Boundary Scan Support

· Low-power IDLE, STANDBY, and HALT Modes

· Development Tools

– F28044 eZdsp Starter Kit

– Code Composer Studio™ IDE With Flash Programming Plug-in

– C28x-optimized ANSI C/C++

Compiler/Assembler/Linker

– DSP/BIOS™ Real-time Operating System which is similar to Clone TMS320F28026 Microprocessor Software Data

– USB-based JTAG Emulators (1)

· Available Software

– C2000™ Digital Power Supply Software Library

– C28x™ IQ Math Library

– C28x Header Files With Example Programs for all Peripherals

– C28x DSP Library

– C28x Digital Motor Control Software Library

· Package Options

– 100-pin Thin Quad Flatpack (PZ)

– 100-pin MicroStar BGA™ (GGM, ZGM)

– RoHS-compliant, Green Packaging

· Temperature Range:

A: –40°C to 85°C (PZ, GGM, ZGM)
